HKS

HIPERMAX IVGT AVE30/GSE31 FULL KIT LEXUSIS 2502014 - 20154GR-FSE

HIPERMAX IVGT AVE30/GSE31 FULL KIT LEXUSIS 2502014 - 20154GR-FSE

$2,760.00 CAD
$2,760.00 CAD $2,760.00 CAD
Sale Sold out
Shipping calculated at checkout.

80230-AT011T

LEXUS
IS 250
2014 - 2015
4GR-FSE

Ride Height mm
  Factory *2 Test data Adjustable range
High - Low *3		 Drivable range
High - Low *4
FRONT Ride height *1 649 ← 675 ～ 603 675 ～ 635
Against stock -26 ← 0 ～ -72 0 ～ -40
REAR Ride height *1 638 ← 663 ～　602 663 ～　602
Against stock -25 ← 0 ～ -61 0 ～ -61
*1. Height from road surface to fender arch.
*2. Height at factory is the data tested at HKS with the setting of Full Kit. (HKS' recommended setting.)
*3. Adjustable range (However, the lowest value may not be road legal.
Even within the adjustable range, car body, arm etc. may contact. In such case, it will be hard to drive.
Damper oil leakage or any other problems caused by low ride height setting from the factory setting will void the warranty of the product.)
*4. Drivable range that there is no contact of car body or arms etc. (However, change of tire/wheel size may cause a problem.)
Caution). Actual data depends on each vehicle.



Kit information
Spring of Full Kit
  F R
Spring rate N/mm(kgf/mm) 78 ( 8 ) 88 ( 9 )
Free height (mm) 250 250
Spring type Straight Straight
Recommended range to change spring rate N/mm(kgf/mm) ±10 (-1～+1) +10 (0～+1)
Specification of damper
  F R
Damping force (Rebound/Damping)N* 1200 / 350 750 / 250
Default position of dial 15 15
Remaining damper stroke (Rebound/Damping)mm 65 / 40 65 / 70
* The value of the damping force is at piston speed of 0.1m/sec.
Setting data
  F R
Default Test Drivable limit
High *		 Drivable limit
Low *		 Default Test Drivable limit
High *		 Drivable limit
Low *
Length of
case (mm)		 422 ← 440 422 459 ← 487 446
Spring
Set length(mm)		 289 ← 289 299 - - - -
Length to ride hight
adjuster (mm)		 34 ← 52 24 R:51 / L:54 ← R:64 / L:67 R:29 / L:32
Lever ratio 1.40 2.00 (spg) , 1.29 (dmp)
* Refer to the above explanation *3 of ride height information for drivable high and low limitations.



Test vehicle information
  F R
Vehicle weight kg - -
Tire size (Air pressure) kPa 225 / 35 - 19 ( 240 ) 255 / 30 - 19 ( 240 )
Wheel size 8.5 JJ × 19 inset 45 9.5 JJ × 19 inset 45
Alignment
(Toe/Camber)		 Test data 0 mm / -1°12' +1.8 mm / -2°18'
Standard value - -
* Test data at HKS.



Parts List * It may be changed without prior notice.
